Trek Emonda SL 5 Disc Bike
Crazy Light. Crazy Fast
Émonda SL 5 Disc is a lightweight carbon road bike with a balanced ride quality, superior handling characteristics, and the added benefit of free speed thanks to aero tube shaping. It's a great choice for century rides on hilly terrain, windy flats, and speedy descents.
Why you'll love it
-
You get a lot for your dollar: Émonda SL 5 Disc is light, fast, fun to ride, and ready to race
-
Aerodynamic tube shaping makes the fastest Émonda SL platform ever—on flats and climbs alike
-
It makes the perfect high-value upgrade from an aluminum road bike
-
Hydraulic disc brakes give you stopping power and control in any weather, on any road
SPECS
| FRAMESET | |
| FRAME | Ultralight 500 Series OCLV Carbon, Ride Tuned performance tube optimisation, tapered head tube, internal routing, DuoTrap S-compatible, flat-mount disc, 142x12 mm thru axle |
| FORK | SR Suntour NEX, coil spring, preload, 100x5mm QR, 63mm travel |
| FRAME FIT | H1.5 Race |
| WHEELS | |
| HUB FRONT | Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle |
| SKEWER FRONT | Bontrager Switch thru axle, removable lever |
| HUB REAR | Bontrager alloy, sealed bearing, CenterLock, Shimano 11-speed freehub, 142x12 mm thru axle |
| SKEWER REAR | Bontrager Switch thru-axle, removable lever |
| RIM | Bontrager Affinity Disc, Tubeless Ready, 24-hole, 21 mm width, Presta valve |
| SPOKES | 14 g stainless steel |
| TIRE | Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x28 c |
| MAX TIRE SIZE | 28 |
| DRIVETRAIN | |
| SHIFTER |
Size: 47, 50, 52
Shimano 105 R7025, short-reach lever, 11-speed Size: 54, 56, 58, 60, 62 Shimano 105 R7020, 11-speed |
| FRONT DERAILLEUR | Shimano 105 R7000, braze-on |
| REAR DERAILLEUR | Shimano 105 R7000, short cage, 30T max cog |
| CRANK |
Size: 47
Shimano 105 R7000, 50/34 (compact), 165 mm length Size: 50, 52 Shimano 105 R7000, 50/34 (compact), 170 mm length Size: 54, 56, 58 Shimano 105 R7000, 50/34 (compact), 172.5 mm length Size: 60, 62 Shimano 105 R7000, 50/34 (compact), 175 mm length |
| BOTTOM BRACKET | Praxis, T47 threaded, internal bearing |
| CASSETTE | Shimano 105 R7000, 11-30, 11-speed |
| CHAIN | Shimano 105 HG601, 11-speed |
| MAX CHAINRING SIZE | 1x: 50T; 2x: 53/39T |
| COMPONENTS | |
| SADDLE |
Size: 47, 50, 52
Bontrager P3 Verse Comp, steel rails, 155 mm width Size: 54, 56, 58, 60, 62 Bontrager P3 Verse Comp, steel rails, 145 mm width |
| SEATPOST |
Size: 47, 50, 52, 54
Bontrager alloy seat mast cap, 10 mm offset, short length Size: 56, 58, 60, 62 Bontrager alloy seat mast cap, 10 mm offset, tall length |
| HANDLEBAR |
Size: 47, 50
Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 38 cm width Size: 52 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 40 cm width Size: 54, 56, 58 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width Size: 60, 62 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width |
| HANDLEBAR TAPE | Bontrager Supertack Perf tape |
| STEM |
Size: 47
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length Size: 50 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length Size: 52, 54 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length Size: 56 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length Size: 58, 60, 62 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length |
| BRAKE ROTOR | Shimano SM-RT70, CenterLock, 160 mm |
| BRAKE | Shimano 105 hydraulic disc, flat mount |
| WEIGHT | |
| WEIGHT | 56 - 9.15 kg / 20.18 lbs |
| WEIGHT LIMIT | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg). |
TECHNOLOGY
500 Series OCLV
500 Series OCLV achieves a superb balance of light weight, strength, and stiffness that's perfectly suited to the sophisticated frame technologies that distinguish Trek frames.
H1.5 Fit
H1.5 geometry, developed with Trek-Segafredo pro cycling teams, puts the rider in the optimal aero race position. It’s the sweet spot for what our racers want.
Ride Tuned Seatmast
Ride Tuned seatmast is designed for the rigors of pro racing. It's the lightest, most comfortable solution for day-in, day-out performance and comfort, however rough the roads or hard the riding.
Select Color
Select Size
From $989.70
Original: $3,299.00
-70%Trek Emonda SL 5 Disc Bike—
$3,299.00
$989.70Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Crazy Light. Crazy Fast
Émonda SL 5 Disc is a lightweight carbon road bike with a balanced ride quality, superior handling characteristics, and the added benefit of free speed thanks to aero tube shaping. It's a great choice for century rides on hilly terrain, windy flats, and speedy descents.
Why you'll love it
-
You get a lot for your dollar: Émonda SL 5 Disc is light, fast, fun to ride, and ready to race
-
Aerodynamic tube shaping makes the fastest Émonda SL platform ever—on flats and climbs alike
-
It makes the perfect high-value upgrade from an aluminum road bike
-
Hydraulic disc brakes give you stopping power and control in any weather, on any road
SPECS
| FRAMESET | |
| FRAME | Ultralight 500 Series OCLV Carbon, Ride Tuned performance tube optimisation, tapered head tube, internal routing, DuoTrap S-compatible, flat-mount disc, 142x12 mm thru axle |
| FORK | SR Suntour NEX, coil spring, preload, 100x5mm QR, 63mm travel |
| FRAME FIT | H1.5 Race |
| WHEELS | |
| HUB FRONT | Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle |
| SKEWER FRONT | Bontrager Switch thru axle, removable lever |
| HUB REAR | Bontrager alloy, sealed bearing, CenterLock, Shimano 11-speed freehub, 142x12 mm thru axle |
| SKEWER REAR | Bontrager Switch thru-axle, removable lever |
| RIM | Bontrager Affinity Disc, Tubeless Ready, 24-hole, 21 mm width, Presta valve |
| SPOKES | 14 g stainless steel |
| TIRE | Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x28 c |
| MAX TIRE SIZE | 28 |
| DRIVETRAIN | |
| SHIFTER |
Size: 47, 50, 52
Shimano 105 R7025, short-reach lever, 11-speed Size: 54, 56, 58, 60, 62 Shimano 105 R7020, 11-speed |
| FRONT DERAILLEUR | Shimano 105 R7000, braze-on |
| REAR DERAILLEUR | Shimano 105 R7000, short cage, 30T max cog |
| CRANK |
Size: 47
Shimano 105 R7000, 50/34 (compact), 165 mm length Size: 50, 52 Shimano 105 R7000, 50/34 (compact), 170 mm length Size: 54, 56, 58 Shimano 105 R7000, 50/34 (compact), 172.5 mm length Size: 60, 62 Shimano 105 R7000, 50/34 (compact), 175 mm length |
| BOTTOM BRACKET | Praxis, T47 threaded, internal bearing |
| CASSETTE | Shimano 105 R7000, 11-30, 11-speed |
| CHAIN | Shimano 105 HG601, 11-speed |
| MAX CHAINRING SIZE | 1x: 50T; 2x: 53/39T |
| COMPONENTS | |
| SADDLE |
Size: 47, 50, 52
Bontrager P3 Verse Comp, steel rails, 155 mm width Size: 54, 56, 58, 60, 62 Bontrager P3 Verse Comp, steel rails, 145 mm width |
| SEATPOST |
Size: 47, 50, 52, 54
Bontrager alloy seat mast cap, 10 mm offset, short length Size: 56, 58, 60, 62 Bontrager alloy seat mast cap, 10 mm offset, tall length |
| HANDLEBAR |
Size: 47, 50
Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 38 cm width Size: 52 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 40 cm width Size: 54, 56, 58 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width Size: 60, 62 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width |
| HANDLEBAR TAPE | Bontrager Supertack Perf tape |
| STEM |
Size: 47
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length Size: 50 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length Size: 52, 54 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length Size: 56 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length Size: 58, 60, 62 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length |
| BRAKE ROTOR | Shimano SM-RT70, CenterLock, 160 mm |
| BRAKE | Shimano 105 hydraulic disc, flat mount |
| WEIGHT | |
| WEIGHT | 56 - 9.15 kg / 20.18 lbs |
| WEIGHT LIMIT | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg). |
TECHNOLOGY
500 Series OCLV
500 Series OCLV achieves a superb balance of light weight, strength, and stiffness that's perfectly suited to the sophisticated frame technologies that distinguish Trek frames.
H1.5 Fit
H1.5 geometry, developed with Trek-Segafredo pro cycling teams, puts the rider in the optimal aero race position. It’s the sweet spot for what our racers want.
Ride Tuned Seatmast
Ride Tuned seatmast is designed for the rigors of pro racing. It's the lightest, most comfortable solution for day-in, day-out performance and comfort, however rough the roads or hard the riding.
